VP · VPB
Vertical Piece - VPB
Vertical post, 82×41 mm back-to-back profile, 2.5 mm gauge.
Photos & drawings
Description
Back-to-back double Flexistrut post specified for vertical loads exceeding the rated capacity of a single VPA post.
Used at the base of taller or more heavily loaded post-and-arm supports within the same range.
Published item codes
| Part number | Thickness (mm) | Length (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|
| VPB-100-A2 | 2.5 | 100 | SS304 | 2.71 | |
| VPB-100-E | 2.5 | 100 | Epoxy on Mild Steel | 2.69 | |
| VPB-100-G | 2.5 | 100 | Hot-Dip Galvanized | 2.69 | |
| VPB-150-A2 | 2.5 | 150 | SS304 | 2.99 | |
| VPB-150-E | 2.5 | 150 | Epoxy on Mild Steel | 2.97 | |
| VPB-150-G | 2.5 | 150 | Hot-Dip Galvanized | 2.97 | |
| VPB-200-A2 | 2.5 | 200 | SS304 | 3.26 | |
| VPB-200-E | 2.5 | 200 | Epoxy on Mild Steel | 3.25 | |
| VPB-200-G | 2.5 | 200 | Hot-Dip Galvanized | 3.25 | |
| VPB-250-A2 | 2.5 | 250 | SS304 | 3.54 |
Not in the list?
Characteristics
| Model | VPB |
|---|---|
| Height | 82 mm |
| Width | 41 mm |
| Thickness | 2.5 mm |
| Material | A2, E, G |
| Finish | A2, E, G |
