45° Elbow
Horizontal elbow for a 45 degree change of direction in a trunking run.
Photos & drawings
Description
The 45° horizontal elbow turns an SCT trunking run in the horizontal plane while keeping the enclosed section of the adjoining straights.
Specified with matching straight sections so the lid line continues through the change of direction.
Published item codes
| Part number | Height (mm) | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|---|
| SCT100-E45-100-1.2-R7-G | 100 | 100 | 1.2 | Hot-Dip Galvanized | 1.09 | |
| SCT100-E45-150-1.2-R7-G | 100 | 150 | 1.2 | Hot-Dip Galvanized | 1.40 | |
| SCT100-E45-200-1.2-R7-G | 100 | 200 | 1.2 | Hot-Dip Galvanized | 1.74 | |
| SCT100-E45-300-1.2-R7-G | 100 | 300 | 1.2 | Hot-Dip Galvanized | 2.54 | |
| SCT150-E45-150-1.2-R7-G | 150 | 150 | 1.2 | Hot-Dip Galvanized | 1.75 | |
| SCT150-E45-200-1.2-R7-G | 150 | 200 | 1.2 | Hot-Dip Galvanized | 2.13 | |
| SCT150-E45-300-1.2-R7-G | 150 | 300 | 1.2 | Hot-Dip Galvanized | 3.01 | |
| SCT25-E45-50-1-R7-G | 25 | 50 | 1 | Hot-Dip Galvanized | 0.34 | |
| SCT300-E45-300-1.2-R7-G | 300 | 300 | 1.2 | Hot-Dip Galvanized | 4.41 | |
| SCT50-E45-50-1.2-R7-G | 50 | 50 | 1.2 | Hot-Dip Galvanized | 0.54 |
Not in the list?
Characteristics
| Model | SCT25, SCT50, SCT75, SCT100, SCT150, SCT300 |
|---|---|
| Thickness | 1 / 1.2 mm |
| Radius | 70 mm |
| Material | G |
| Finish | G |
