ART · T-LC
Equal Tee Cover
Lipped cover for the equal tee fitting.
Photos & drawings
Description
Lipped cover for the equal tee, providing continuous enclosure over the branch junction.
Installed directly over the corresponding tee fitting; specify one cover per tee within the same system and model.
Published item codes
| Part number | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|
| ART-T-LC-50-1.5-R30-A4 | 50 | 1.5 | SS316L | 5.13 | |
| ART-T-LC-50-1.5-R30-G | 50 | 1.5 | Hot-Dip Galvanized | 5.07 | |
| ART-T-LC-50-2-R30-A4 | 50 | 2 | SS316L | 6.85 | |
| ART-T-LC-50-2-R30-G | 50 | 2 | Hot-Dip Galvanized | 6.76 | |
| ART-T-LC-75-1.5-R30-A4 | 75 | 1.5 | SS316L | 5.55 | |
| ART-T-LC-100-1.5-R30-A4 | 100 | 1.5 | SS316L | 5.99 | |
| ART-T-LC-100-1.5-R30-G | 100 | 1.5 | Hot-Dip Galvanized | 5.91 | |
| ART-T-LC-100-2-R30-A4 | 100 | 2 | SS316L | 7.98 | |
| ART-T-LC-100-2-R30-G | 100 | 2 | Hot-Dip Galvanized | 7.88 | |
| ART-T-LC-125-1.5-R30-A4 | 125 | 1.5 | SS316L | 6.43 |
Not in the list?
Characteristics
| Model | ART50 |
|---|---|
| Height | 50 mm |
| Thickness | 1.5 / 2 mm |
| Radius | 300 mm |
| Material | A4, Hot-Dip Galvanized |
| Finish | A4, G |
