ART · EP
End Plate
End plate for closing off tray run ends.
Photos & drawings
Description
End plate closing the open end of a cable tray run, enclosing exposed cable ends and the tray profile at the termination of a route.
Specified at every dead end of a run; not required where the run continues into a fitting or an additional straight section.
Published item codes
| Part number | Height (mm) | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|---|
| ART50-EP-50-1.5-A4 | 50 | 50 | 1.5 | SS316L | 0.11 | |
| ART50-EP-50-1.5-G | 50 | 50 | 1.5 | Hot-Dip Galvanized | 0.11 | |
| ART50-EP-50-2-A4 | 50 | 50 | 2 | SS316L | 0.15 | |
| ART50-EP-50-2-G | 50 | 50 | 2 | Hot-Dip Galvanized | 0.14 | |
| ART50-EP-100-1.5-A4 | 50 | 100 | 1.5 | SS316L | 0.17 | |
| ART50-EP-100-1.5-G | 50 | 100 | 1.5 | Hot-Dip Galvanized | 0.16 | |
| ART50-EP-100-2-A4 | 50 | 100 | 2 | SS316L | 0.22 | |
| ART50-EP-100-2-G | 50 | 100 | 2 | Hot-Dip Galvanized | 0.22 | |
| ART50-EP-125-1.5-A4 | 50 | 125 | 1.5 | SS316L | 0.20 | |
| ART50-EP-125-1.5-G | 50 | 125 | 1.5 | Hot-Dip Galvanized | 0.19 |
Not in the list?
Characteristics
| Model | ART50, ART75 |
|---|---|
| Thickness | 1.5 / 2 mm |
| Material | A4, Hot-Dip Galvanized |
| Finish | A4, G |
