ART · CP-LC
Equal Cross Cover
Lipped cover for the equal cross fitting.
Photos & drawings
Description
Lipped cover for the equal cross, providing continuous enclosure across all four branches of the junction.
Installed directly over the corresponding cross fitting; specify one cover per cross within the same system and model.
Published item codes
| Part number | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|
| ART-CP-LC-50-1.5-R30-A4 | 50 | 1.5 | SS316L | 9.38 | |
| ART-CP-LC-50-1.5-R30-G | 50 | 1.5 | Hot-Dip Galvanized | 9.26 | |
| ART-CP-LC-50-2-R30-A4 | 50 | 2 | SS316L | 12.50 | |
| ART-CP-LC-50-2-R30-G | 50 | 2 | Hot-Dip Galvanized | 12.35 | |
| ART-CP-LC-100-1.5-R30-A4 | 100 | 1.5 | SS316L | 10.47 | |
| ART-CP-LC-100-1.5-R30-G | 100 | 1.5 | Hot-Dip Galvanized | 10.34 | |
| ART-CP-LC-100-2-R30-A4 | 100 | 2 | SS316L | 13.96 | |
| ART-CP-LC-100-2-R30-G | 100 | 2 | Hot-Dip Galvanized | 13.78 | |
| ART-CP-LC-125-1.5-R30-A4 | 125 | 1.5 | SS316L | 11.04 | |
| ART-CP-LC-125-1.5-R30-G | 125 | 1.5 | Hot-Dip Galvanized | 10.90 |
Not in the list?
Characteristics
| Model | ART50 |
|---|---|
| Height | 50 mm |
| Thickness | 1.5 / 2 mm |
| Radius | 300 mm |
| Material | A4, Hot-Dip Galvanized |
| Finish | A4, G |
