AML · ESP
Expansion Splice Plate
Expansion splice plate for joining ladder sections.
Photos & drawings
Description
Splice plate permitting a straight ladder run to expand and contract along its length, specified where thermal movement or an extended unbroken run requires a slip joint in place of a fixed splice.
Installed in place of a standard splice plate at the joint identified on the layout drawing; not required at every joint within the run.
Published item codes
| Part number | Height (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|
| AML100-ESP-1.5-G | 100 | 1.5 | Hot-Dip Galvanized | 0.45 | |
| AML100-ESP-2-G | 100 | 2 | Hot-Dip Galvanized | 0.60 | |
| AML125-ESP-1.5-G | 125 | 1.5 | Hot-Dip Galvanized | 0.53 | |
| AML125-ESP-2-G | 125 | 2 | Hot-Dip Galvanized | 0.70 | |
| AML150-ESP-1.5-G | 150 | 1.5 | Hot-Dip Galvanized | 0.61 | |
| AML150-ESP-2-G | 150 | 2 | Hot-Dip Galvanized | 0.81 |
Not in the list?
Characteristics
| Model | AML100, AML125, AML150 |
|---|---|
| Thickness | 1.5 / 2 mm |
| Material | Hot-Dip Galvanized |
| Finish | G |
