AS · AS100T3
Flexistrut Channel Slotted - AS100T3
AS100 profile with three rows of slotted holes for bolt-anywhere fixing.
Photos & drawings
Description
Single-channel Flexistrut section with slotted holes on three faces, permitting fixings from multiple sides of the channel for more complex bracket arrangements.
Specified where accessories are required to fix from more than one face of the channel; the plain AS100 or single-slot AS100T1 is sufficient for simpler installations.
Published item codes
| Part number | Thickness (mm) | Length (m) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|
| AS100T3-3000-A2 | 2.5 | 3 | SS304 | 8.28 | |
| AS100T3-3000-E | 2.5 | 3 | Epoxy on Mild Steel | 8.35 | |
| AS100T3-3000-G | 2.5 | 3 | Hot-Dip Galvanized | 8.35 | |
| AS100T3-6000-A2 | 2.5 | 6 | SS304 | 16.56 | |
| AS100T3-6000-E | 2.5 | 6 | Epoxy on Mild Steel | 16.71 | |
| AS100T3-6000-G | 2.5 | 6 | Hot-Dip Galvanized | 16.71 |
Not in the list?
Characteristics
| Model | AS100T3 |
|---|---|
| Height | 41 mm |
| Width | 41 mm |
| Thickness | 2.5 mm |
| Material | A2, E, G |
| Finish | A2, E, G |
GA drawings & documents
| Document | Type | Applies to | Revision | Download |
|---|---|---|---|---|
| AS Flexistrut Channel Slotted - AS100T3 — GA Drawing | General arrangement (GA) | AS/AS100T3 | — |
GA drawings and spec sheets are published per component and cover every width and length in the range. Project-specific GA sheets for a particular item code are issued against an enquiry reference.
