ALT · T
Equal Tee
Three-way branch fitting joining tray runs of equal width.
Photos & drawings
Published item codes
| Part number | Height (mm) | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|---|
| ALT15-T-50-1.5-R30-A4 | 15 | 50 | 1.5 | SS316L | 4.53 | |
| ALT15-T-50-1.5-R30-G | 15 | 50 | 1.5 | Hot-Dip Galvanized | 5.57 | |
| ALT15-T-50-2-R30-A4 | 15 | 50 | 2 | SS316L | 6.04 | |
| ALT15-T-50-2-R30-G | 15 | 50 | 2 | Hot-Dip Galvanized | 7.42 | |
| ALT15-T-100-1.5-R30-A4 | 15 | 100 | 1.5 | SS316L | 5.33 | |
| ALT15-T-100-1.5-R30-G | 15 | 100 | 1.5 | Hot-Dip Galvanized | 6.44 | |
| ALT15-T-100-2-R30-A4 | 15 | 100 | 2 | SS316L | 7.11 | |
| ALT15-T-100-2-R30-G | 15 | 100 | 2 | Hot-Dip Galvanized | 8.59 | |
| ALT15-T-125-1.5-R30-A4 | 15 | 125 | 1.5 | SS316L | 5.75 | |
| ALT15-T-125-1.5-R30-G | 15 | 125 | 1.5 | Hot-Dip Galvanized | 6.90 |
Not in the list?
Characteristics
| Model | ALT15, ALT25 |
|---|---|
| Thickness | 1.5 / 2 mm |
| Radius | 300 mm |
| Material | A4, G |
| Finish | A4, G |
