ALT · CP
Equal Cross
Four-way branch fitting joining tray runs of equal width.
Photos & drawings
Published item codes
| Part number | Height (mm) | Width (mm) | Thickness (mm) | Finish | Weight (kg) | Enquiry |
|---|---|---|---|---|---|---|
| ALT15-CP-50-1.5-R30-A4 | 15 | 50 | 1.5 | SS316L | 10.02 | |
| ALT15-CP-50-1.5-R30-G | 15 | 50 | 1.5 | Hot-Dip Galvanized | 9.90 | |
| ALT15-CP-50-2-R30-A4 | 15 | 50 | 2 | SS316L | 13.37 | |
| ALT15-CP-50-2-R30-G | 15 | 50 | 2 | Hot-Dip Galvanized | 13.20 | |
| ALT15-CP-100-1.5-R30-A4 | 15 | 100 | 1.5 | SS316L | 11.15 | |
| ALT15-CP-100-1.5-R30-G | 15 | 100 | 1.5 | Hot-Dip Galvanized | 11.01 | |
| ALT15-CP-100-2-R30-A4 | 15 | 100 | 2 | SS316L | 14.87 | |
| ALT15-CP-100-2-R30-G | 15 | 100 | 2 | Hot-Dip Galvanized | 14.68 | |
| ALT15-CP-125-1.5-R30-A4 | 15 | 125 | 1.5 | SS316L | 11.74 | |
| ALT15-CP-125-1.5-R30-G | 15 | 125 | 1.5 | Hot-Dip Galvanized | 11.59 |
Not in the list?
Characteristics
| Model | ALT15, ALT25 |
|---|---|
| Thickness | 1.5 / 2 mm |
| Radius | 300 mm |
| Material | A4, G |
| Finish | A4, G |
